The Simplex 49AO-APPLC is a TrueAlert ES ceiling-mount addressable horn for audible notification on Simplex intelligent fire alarm systems, communicating individually over the IDNet2 signaling line circuit.

Compliance

• UL 464 listed audible signaling appliance
• NFPA 72 National Fire Alarm and Signaling Code installations
• FM Approved
• ULC-S525 compatible for Canadian installations

Key features

• TrueAlert ES addressable horn for the Simplex intelligent notification platform
• Individual addressing and supervision over the IDNet2 signaling line circuit
• Operates on regulated 24 VDC notification appliance power
• Ceiling-mount form factor for corridors, lobbies, and open areas
• Selectable temporal-3 and continuous tone patterns set per device
• Electronic supervision and load reporting handled by the addressable loop
• Coordinated synchronization across TrueAlert ES appliances on the circuit

TrueAlert ES is the addressable notification family for Simplex 4100ES, 4010ES, and 4007ES panels, where each horn, strobe, or combination appliance carries its own address rather than wiring as a conventional notification appliance circuit. Addressing the appliance directly lets the panel set tone and output on a per-device basis, supervise each unit, and report load at the appliance, which simplifies circuit design and survey verification compared with conventional NAC wiring.

Verify panel and device family compatibility before ordering.
