Mircom MIX-M500SAP addressable photoelectric smoke detector from the M500 intelligent device series for FleX-Net networked fire alarm control panels.

Compliance

• UL 268
• NFPA 72
• ULC Listed
• FCC compliant

Key features

• Addressable photoelectric sensing chamber engineered for stable smoke detection across a wide range of commercial and institutional occupancies
• SLC loop communication compatible with Mircom FleX-Net intelligent fire alarm platforms and MIX-NRX networking panels
• Operating voltage range typical of M500 series: 15 to 32 VDC over the SLC loop with low standby current draw during normal polling
• Operating temperature 32°F to 100°F (0°C to 38°C) and humidity 10% to 93% RH non-condensing per the M500 series envelope
• Field-set or programmer-set device address required prior to installation on the loop

The Mircom M500 series is Mircom’s intelligent addressable detector family used with FleX-Net networked fire alarm systems and the broader MIX-NRX intelligent platform. The M500SAP photoelectric model targets general-purpose smoke detection where a photoelectric chamber is preferred over heat or ionization sensing. As with all addressable devices on a Mircom SLC, the detector must be addressed and reported in the panel program before commissioning, and base compatibility must be confirmed against the M500 series base options published by Mircom. ULC listing covers Canadian installations alongside the UL 268 and NFPA 72 compliance for US projects.

Verify panel/device family compatibility before ordering.
