Fire-Lite
Fire-Lite ECC-50W-70V Emergency Voice Evacuation Amplifier
10 in stock
Fire-Lite ECC-50W-70V 50-watt 70-volt audio amplifier for the ECC Emergency Command Center.
Compliance
- UL 2572 listed (mass notification)
- UL 864 listed
- UL 1480 listed (speakers)
- NFPA 72 compatible
Key features
- 50-watt amplifier output at 70 V for 25-ohm or 70-volt distributed speaker systems
- Installs as a module within the ECC-50/100 chassis
- Supports pre-recorded and live voice message broadcasting across assigned audio zones
- Designed for NFPA 72 Chapter 24 emergency voice systems in commercial occupancies
The 70-volt distributed audio standard is widely used in commercial fire alarm voice evacuation systems because it allows many speakers to be wired in series-parallel configurations at lower line current, reducing cable gauge requirements across large buildings. The ECC-50W-70V provides 50 watts of amplified 70 V output within the ECC chassis and is designed for zoned voice evacuation or mass notification applications where audio zones must be individually controlled. Amplifier module count and speaker tap wattages must be engineered to match the system's zone load requirements.
Verify panel/device family compatibility before ordering.
