Vesda E700-SP-DCL discreet concealed label sampling point for VESDA aspirating smoke detection capillary networks.

Compliance

• UL 94 flammability rating (V-O flame retardant)
• UL 1887 listed for use in plenum-rated areas
• ULC smoke and flame ratings
• Compliant with NFPA 72 air sampling requirements

Key features

• Miniature sampling point with discreet, low-profile label for aesthetic-sensitive ceilings
• Connects directly to E700-TUBE 3/8" capillary tubing for above-ceiling concealed sampling
• Pilot sampling hole sized for standard VESDA pipe network calculations
• Used to extend sampling coverage from the main CPVC pipe network into the protected space
• Lightweight thermoplastic construction installs flush in finished ceiling tiles or panels

VESDA by Honeywell (formerly Xtralis) capillary sampling points are part of the integrated VESDA Pipe and Fittings system, engineered to deliver the sampling network geometry required for very early smoke detection. The E700-SP-DCL is specified in data centers, server rooms, museums, archives, and any environment where exposed sampling holes would be visually intrusive but air sampling coverage must still meet the design density.

Verify panel/device family compatibility before ordering.
