Silent Knight SK-MON-10 Addressable Ten-Input Monitor Module.

Compliance

• UL Listed

Key features

• Monitors up to ten Class B initiating circuit zones from one addressable module
• Standby current 3.5 mA max; weight 6.3 oz (196 g)
• Operating temperature 32°F to 120°F (0°C to 49°C), 10% to 93% humidity
• High input density reduces total SLC address consumption for large conventional zone systems
• Connects legacy conventional detection zones to the SK addressable SLC

The SK-MON-10 is an addressable ten-input monitor module for the Silent Knight SK protocol SLC. It aggregates up to ten conventional initiating device circuit zones under a single SLC address, significantly reducing addressable point consumption in systems with many conventional zones. Used with 5820XL and 6500 series fire alarm control panels (a Honeywell brand), it is well suited for retrofit conversions of large conventional systems. Confirm zone input wiring style and total supervised circuit loading against the SK-MON-10 installation documentation before ordering.

Verify panel/device family compatibility before ordering.
