Silent Knight 005860TR Remote LCD Annunciator (Red Trim).

Compliance

• UL Listed
• NFPA 72
• CSFM Approved
• MEA 429-92-E
• FM Approved

Key features

• 80-character backlit LCD (4 lines x 20 characters) for event and status readout
• Tactile and audible feedback keypad; accepts user codes or fire fighter's key
• Five status LEDs: alarm, supervisory, trouble, silence, and AC power; on-board piezo sounder
• RS-485 SBUS interface; up to 8 units per system, wiring up to 6,000 ft from the FACP
• Standby 20 mA max, alarm 25 mA at 24 VDC; red trim (TR) housing variant

The 005860TR is the red trim (TR) housing variant of the Silent Knight 5860 remote LCD annunciator for 5820XL and 6500 series fire alarm control panels (a Honeywell brand). The red enclosure matches the standard fire alarm color coding used in many jurisdictions for visible identification of life safety equipment. Display and key interface mirror the panel's built-in annunciator, supporting operator acknowledgment, silence, and reset from secondary locations. MEA and CSFM listings cover New York City and California installations. Up to eight 005860 series units operate per system on the SBUS RS-485 network.

Verify panel/device family compatibility before ordering.
