Silent Knight 005860TG Remote LCD Annunciator (Light Gray).

Compliance

• UL Listed
• NFPA 72
• CSFM Approved
• MEA 429-92-E
• FM Approved

Key features

• 80-character backlit LCD (4 lines x 20 characters) for event and status readout
• Tactile and audible feedback keypad; accepts user codes or fire fighter's key
• Five status LEDs: alarm, supervisory, trouble, silence, and AC power; on-board piezo sounder
• RS-485 SBUS interface; up to 8 units per system, wiring up to 6,000 ft from the FACP
• Standby 20 mA max, alarm 25 mA at 24 VDC; light gray (TG) housing variant

The 005860TG is the light gray (TG) housing variant of the Silent Knight 5860 remote LCD annunciator for 5820XL and 6500 series fire alarm control panels (a Honeywell brand). Its display and key interface mirror the panel's built-in annunciator, enabling operators to acknowledge alarms, silence notification, and reset the system from a secondary location such as a building entrance or fire command center. MEA and CSFM listings support New York City and California installations. Up to eight 005860 series units can operate per system on the SBUS RS-485 network.

Verify panel/device family compatibility before ordering.
