The Gamewell-FCI SLP-RED is the red-door variant of the S3 Series Smart Loop Panel, a digital, microprocessor-based addressable fire alarm control panel designed for small to mid-sized installations. The basic configuration consists of the SLP main board, the LCD-SLP touchscreen display, SLC loop personality modules, and a 7-amp FLPS-7 power supply. Black S3 SLP-BB enclosure with a red door.

The SLP main board carries one or two SLC loops in Class A or Class B configuration. With System Sensor protocol the panel supports up to 318 devices per loop (636 across two loops). With Apollo protocol the panel supports up to 126 devices per loop (252 across two loops). Four Class B or two Class A NACs deliver 2.0 A each, 6.0 A total, with strobe sync for System Sensor, Cooper-Wheelock, and Gentex appliances and an auto-EOL feature that adjusts to legacy 1k-55k Ω EOL resistors.

Networking and node count

The S3 Series operates standalone or networks with E3 Series and 7100 Series panels via the RPT-E3-UTP repeater. Up to 122 nodes in S3 / E3 mode, 64 nodes with 7100. The network bus runs at 625K baud ARCNET over twisted-pair or fiber-optic links.

Annunciator and display options

The standard display is the LCD-SLP, a 4.3-inch color touchscreen with five programmable switches. Up to five LCD-7100 remote annunciators per panel, plus up to 16 ASM-16 modules and up to 16 ANU-48 LED driver modules. The LCD-E3 is an alternative to the LCD-SLP for E3-Series-style touchscreen control.

Loop card options

SLC-PM is the System Sensor protocol loop card (1 loop, 159 sensors + 159 modules). SLC95-PM is the Apollo protocol loop card (1 loop, 126 sensors + modules). Pick by detector protocol, the panel itself accommodates either card.

Specs and listings

Input voltage: 120 VAC 60 Hz or 240 VAC 50-60 Hz. Input current: 2.75 A max @ 120 VAC, 1.4 A max @ 240 VAC. Aux 24 VDC at 1.75 A total. Listed per the 9021-60730 datasheet revision H.
