The Gamewell-FCI LCD-E3, LCD keypad display for E3 Broadband systems. Up to 6 per system; Region 0 grants global system access.

LCD annunciator for E3 Broadband

The LCD-E3 is the standard LCD keypad display for E3 Series Broadband systems. Each E3 network supports up to six LCD-E3 displays, one as the primary system annunciator at the panel location, the other five as remote annunciators at building entrances, fire command rooms, lobby information desks, or floor-level locations.

Region 0, global system access

Each LCD-E3 is assigned a "region", a logical grouping of nodes whose status the display can monitor and control. Region 0 is special: it grants global access across the entire E3 network, with all events visible and all programmable controls accessible. Region 0 displays sit at the primary fire command location. Regional displays (Region 1, 2, etc.) are scoped to specific buildings or zones.

LCD-E3 vs LCD-SLP vs LCD-7100

LCD-E3 is the E3-Series-style keypad display. LCD-SLP is the touchscreen variant used with S3 Series panels (and compatible with E3 in some configurations). LCD-7100 is the serial remote annunciator used with 7100 Series panels, up to 5 per system, separately from the LCD-E3 count. Pick by panel family.

Listings and approvals

UL Listed S1869 under UL 864 9th Edition and UL 2572. FM Approved 3025415. MEA FDNY 6175 231-06-2E. CSFM 7165-1703:125. ISO 9001 manufacturing.
