The Gamewell-FCI E3BB-RA2, A2-size E3 cabinet sized for a remote LCD-E3 or LCD-SLP annunciator. Red door, 16-gauge steel backbox.

A2 cabinet sized for remote annunciator

A2 measures 13.25 inches wide × 10 inches tall × 4.5 inches deep, the form factor for a single LCD-E3 or LCD-SLP touchscreen mounted at a remote location (building entrance, fire command room, lobby annunciator). The 1-slot inner door is pre-cut for the display. For larger inner-door layouts with switches and graphic annunciators, step up to a B or C size cabinet.

Red versus black, picking by jurisdiction

The E3BB-RA2 has a red outer door; the E3BB-BA2 is the all-black equivalent. Hardware and listings are identical. Some AHJ jurisdictions require red enclosures for any fire-related panel housing; design-sensitive public installations (hotel lobbies, modern offices) often prefer black. Match facility code first, then aesthetics.

Construction

16-gauge steel backbox with removable outer and inner doors. Inner-door bonding strap maintains grounding continuity. Lexan window on the outer door. Door opens 90 degrees with zero clearance or 180 degrees with full clearance. Keylock with quarter-turn latch. Backbox and door ground studs for positive grounding.

Listings and approvals

UL Listed S1869 under UL 864 10th Edition and UL 2572 2nd Edition. UUKL for smoke control. FM Approved 3025415. MEA FDNY COA# 6077. CSFM 7165-1703-0125. VMA Seismic Certified. IBC 2000-2013 / CBC 2007 seismic codes. ISO 9001 manufacturing.
