The Gamewell-FCI E3BB-BC/INX, C-size E3 cabinet for INCC command center or INX audio transponder. Louvered black housing, 19.375 × 30 × 4.5 inches.

C-size enclosure for INCC or INX

C size measures 19.375 inches wide × 30 inches tall × 4.5 inches deep, the cabinet sized for the INCC (Intelligent Network Command Center) or the INX (Intelligent Network Transponder). INCC builds use this cabinet to house the INI-VGC voice gateway plus ASM-16 switch modules and optional NGA. INX builds use it for the INI-VGX voice transponder plus up to four AM-50 amplifiers and the PM-9 power supply.

Louvered design for amplifier heat dissipation

C-size cabinets used for INX configurations have a louvered outer door rather than a Lexan window, amplifier heat from AM-50 modules requires ventilated airflow. INCC builds without amplifiers can still use the louvered cabinet; the louvers do not affect operation when the cabinet houses only switch and gateway modules.

Construction and listings

16-gauge steel backbox, removable inner door with bonding strap, multiple conduit knockouts. Keylock quarter-turn latch. UL Listed S1869 under UL 864 10th Edition and UL 2572 2nd Edition. UUKL for smoke control. FM Approved 3025415. VMA Seismic Certified.
