The Gamewell-FCI 1100-0503, Remote LED driver module for E3 Broadband. 48 programmable LEDs for zone status, expandable for graphic annunciator panels.

LED-based zone annunciation

The 1100-0503 (ANU-48) is the remote LED driver module that lets E3 Broadband systems drive 48 programmable LEDs from one inner-door slot. The LEDs are typically used for zone status, building-floor indicators, or custom graphic-annunciator overlay points, each LED is independently programmable to track a specific event or device state.

ANU-48 vs NGA, pick by visual model

The ANU-48 drives discrete LEDs, suited for installations with a pre-printed building floor plan or a static graphic overlay where each LED maps to a known physical zone. The NGA drives a touchscreen with up to 512 user-defined message strings, more flexible for installations needing custom text or runtime-configurable layouts. Pick by visual model: fixed-graphic with LEDs = ANU-48; touchscreen with messages = NGA.

Inner-door slot and mounting

Each ANU-48 occupies one inner-door slot in the INCC C or D cabinet. Mounts using standard module fastening hardware. For installations needing more than 48 LEDs, multiple ANU-48 modules stack into adjacent inner-door slots.

Listings and approvals

UL Listed S1869 under UL 864 9th Edition and UL 2572. FM Approved 3025415. MEA FDNY 6175 231-06-2E. CSFM 7165-1703:125. ISO 9001 manufacturing.
