The Gamewell-FCI 1100-0461, B-size INX-CAB audio transponder enclosure variant for distributed-audio nodes. Black door, ventilation-tuned for amplifier heat.

B-size INX-CAB audio transponder enclosure

The 1100-0461 is the B-size INX-CAB variant tuned specifically for audio transponder duty, distinct door / louver configuration from the 1100-0460 backbox-with-door variant. Use this SKU for INX nodes where the AM-50 amplifier heat load needs the ventilated louver pattern rather than the standard Lexan-window door.

1100-0461 vs 1100-0460

Both are B-size INX cabinets. The 1100-0461 is the audio transponder enclosure variant (ventilated). The 1100-0460 is the backbox-with-door variant (standard door). Match by amplifier heat-load expectation: high-utilization audio transponder = 1100-0461; light-utilization or non-audio = 1100-0460. Confirm with the current Gamewell-FCI cabinet datasheet revision before specifying.

Construction and listings

16-gauge steel backbox. Ventilation-tuned door for amplifier heat dissipation. Standard E3 mounting patterns for INX sub-assemblies. UL Listed S1869 under UL 864 10th Edition and UL 2572 2nd Edition. UUKL for smoke control. FM Approved 3025415.

Specify with the parent E3 cabinet

Order alongside the matching E3 cabinet, inner door, and mounting hardware to keep the assembly under one listed configuration. Confirm the current Gamewell-FCI part-number cross-reference and revision against the 9020-0649 cabinet datasheet before specifying for jurisdiction-sensitive projects so that the as-built record matches the published listing matrix.
