The Gamewell-FCI 1100-0460, B-size INX transponder backbox with integrated black door, 19-inch frame, for distributed-audio node housing.

B-size INX backbox with integrated door

The 1100-0460 is the B-size INX transponder enclosure with a 19-inch backbox and an integrated black door. Use this SKU when an INX (Intelligent Network Transponder) needs a standalone housing, typical for distributed-audio nodes that serve one floor or wing of a larger building, where the INI-VGX voice transponder plus PM-9 power supply and one or two AM-50 amplifiers fit the B form factor.

1100-0460 vs 1100-0461

Both are B-size INX cabinets. The 1100-0460 is the backbox-with-door variant, door already attached. The 1100-0461 is the audio transponder enclosure variant with a different door / louver configuration. Match by exact application: confirm with the current Gamewell-FCI cabinet datasheet revision against the specific INX build requirements.

Construction and listings

16-gauge steel backbox. Mounting patterns for INX sub-assemblies. Multiple knockouts for conduit access. UL Listed S1869 under UL 864 10th Edition and UL 2572 2nd Edition. UUKL for smoke control. FM Approved 3025415. MEA FDNY COA# 6077. CSFM 7165-1703-0125. VMA Seismic Certified.
