Fire-Lite MR-201/CR MR-Series Relay Module
32 in stock
Fire-Lite MR-201/CR MR-Series multi-voltage relay module with clear cover and higher-current contacts.
Compliance
- UL listed
- NFPA 72 compatible auxiliary control relay
Key features
- Single relay contact rated for higher-current load switching than the MR-101 base model
- Multi-voltage coil operates on 24 VDC, 24 VAC, or 120 VAC nominal
- Clear polycarbonate enclosure with mounting flanges for surface or backbox installation
- LED indication of coil energization state
- Field-replaceable relay socket for service without rewiring
- Suitable for higher-load HVAC fan, blower, or damper actuator control
The MR-201/CR is positioned within the MR-Series for control functions that exceed the contact rating of the entry-level MR-101 — typically larger HVAC blower contactors, makeup-air dampers, smoke-control motorized dampers, or similar inductive loads that draw inrush current beyond the standard 10A spec. The multi-voltage coil and clear-cover format are common across the MR family, which simplifies inventory for service technicians stocking auxiliary control relays for life-safety interface work. Confirming the connected load current, voltage, and inductive characteristic against the relay contact rating is required during system design.
Verify panel/device family compatibility before ordering.
