The Edwards 757-4A-T is a wall-mount temporal horn-strobe for Edwards 757 Series notification appliance circuits, compatible with Genesis synchronization.

Specifications

• 75 cd strobe (75 cd wall, 60 cd ceiling), UL 1971 and UL 1638 Listed
• Temporal-3 horn with field-selectable steady tone, 98 dBA high / 94 dBA low at 10 ft
• 16-33 VDC operation, separate polarized horn and strobe inputs, #12 AWG maximum
• Red engineered-plastic housing on a single-screw mounting plate

Mounting and compatibility

Flush-mounts to a North American 2-gang box, or installs outdoors with the 757A-WB weatherproof backbox. Synchronizes with Genesis and Integrity sync sources for UL 1971 strobe timing under NFPA 72.
